Precision Piercing Needles are sterilized using EO - Ethylene Oxide Gas and each needle comes packaged in a tri-beveled sterilized pouch. These piercing needles come in box sizes of 100, 50 or 25 per gauge, depending on the gauge chosen. The chart below outlines the gauge, inner diameter, thickness of the tube, and the number of needles per box.
Specifications:
Piercing Needle By Gauge Chart
Specifications:
- EO - Ethylene Oxide Gas Sterilized
- Each individual needle is packaged in a sterilized pouch
- Sizes Available: 20g through 10g
- Material: 316L Stainless Steel
Piercing Needle By Gauge Chart
| Gauge (Outer Diameter) | Inner Diameter | Thickness of Tube | Number of Needles Per Box |
| 20g~0.8mm | 0.43mm | 0.18mm | Box of 100 |
| 18g~1.03mm | 0.67mm | 0.18mm | Box of 100 |
| 16g~1.26mm | 0.90mm | 0.18mm | Box of 100 |
| 14g~1.62mm | 1.26mm | 0.18mm | Box of 100 |
| 12g~2.10mm | 1.70mm | 0.20mm | Box of 100 |
| 11g~2.38mm | 1.98mm | 0.20mm | Box of 50 |
| 10g~2.76mm | 2.36mm | 0.20mm | Box of 50 |
